Product center

Vehicle GPS tracker VT-360


Introduction
VT360 is a GPS/GSM/GPRS tracking device specially developed and designed for vehicle real-time tracking and fleet management. With superior GPS and GPRS modules, VT360 has good sensitivity and stable performance. It can get accurate GPS fix even in remote places.

Feature
Support sms link with google map
Track by SMS/GPRS
Current location report
Mileage report via SMS /GPRS
Track on Mobile Phone
Track by time interval
Track by distance interval
Internal Backup Battery
SOS Alarm
Geo-fence Alarm
GPS Blind Area Alarm
Low Battery Alarm
Overspeed Alarm
Engine Cut (Stop Engine)
Wiretapping / remote listenning
2 Inputs
2 Outputs
Analog input: 1 Analog input for temperature / Fuel sensor monitoring and detecting



Specification



Items

Specification

Power Supply

+9V - +40V

SIM card type

3 V

Normal power consumption

Active mode (peak)<1.0A     Active mode(avg.)<300mA

Dimension

75mm x 54mm x 25mm

External Antenna

Connected via 50Ω coax connector

Weight

123g

Operating temperature

-20° to 70° C

Humidity

up to 75% Non-condensing

Frequency

GSM 900/1800/1900Mhz or GSM 850/900/1800/1900Mhz (optional)

GPS Chipset

latest GPS SIRF-Star III chipset

Sensitivity

-104 dBm minimum for E-GSM 900 and 850

-102 dBm minimum for DCS 1800

-102 dBm minimum for PCS 1900

GPS Frequency

L1, 1575.42 MHz

C/A Code

1.023 MHz chip rate

Channels

20 channel all-in-view tracking

Position Accuracy

10 meters, 2D RMS

Velocity Accuracy

0.1 m/s

Time Accuracy

1 us synchronized to GPS time

Default datum

WGS-84

Reacquisition

0.1 sec., average

Hot start

1 sec., average

Warm start

38 sec., average

Cold start

42 sec., average

Altitude Limit

18,000 meters (60,000 feet) max.

Velocity Limit

515 meters/second (1000 knots) max.

Button

One SOS button and 1 power on/off

Interface

Two digital inputs (1 postive triggering and 1 negative triggering

Two outputs

One Analog input







Standard Accessories

1 GPS Antenna

1 GSM Antenna

1 Set of socket cables

1 Relay

1 Microphone

1 User manual
